SAMBRAN PROG500
Features:
• Supports all ATMEL-AVR MCU’s such as AT90 , ATMEGA , ATTINY , etc.
• One 40-pins ZIF socket to use easier from DIP packages
• USB2.0 high-speed connection
• No power required , powered through USB
• Compatibles with STK500 Protocol
• High speed programming
• External oscillator to choose external clock
• Easy adjust to choose fuse bits and lock bits
• Small and slim size to easy carry , 112mm X 29mm
• Direct connection to computer (no interface cable required)
• Jumper Wires 6 – Female to Male for target programming on Breadboard.
• Reserved MOSI, MISO, RET, SCK, VCC, GND. 6PIN interface, user-freindly connection to the target board.
• Compatibles with “Progisp”, “Khazama AVR Programmer”, “AVRDUDE”, “BASCOM-AVR” and “eXtreme Burner – AVR” software.
• Standard 10-pin ISP Connector,
• With USB power and target board support target voltage 5V, can be selected through the jumper cap connection
Introduction:
The PROG500 is a complete programmer system for the AVR Flash microcontroller from Sambran Corporation. PROG500 can be directly connected with the computer USB port and this product is a USB in-circuit programmer for Atmel AVR microcontrollers. The hardware consists of an AVR microcontroller and other passive components while the programmer uses firmware-only USB driver. This programmer is based on STK500 open source USBasp design and connects to your computer’s USB port and is quite compact and elegant.
Details:
1- USB Connector
2- Dip Switch for Select Low or
High Speed Programming mode
3- Power and Status LED
4- Zif Socket
5- Output Pins for target Programming
6- ISP Connector
7- External oscillator socket
8- Target Placement guide
9- SMD fuse protected power
10- Jumper for select programmer PS
Reserve Pins:
1- Vcc (target)
2- Ground
3- MISO
4- MOSI
5- SCK
6- RST (reset)
How to put target IC on the zif socket?
Follow pictures:
Download drivers and software:
